Primus-RP 900 TST
Ord. no. 614140The advantages of the Primus series, combined with a powerful Kränzle in-line piston pump: The Primus-RP 900 TST model achieves a working pressure of 180 bar at a water output of 15 l/min, thus extending the range of applications and application possibilities of the Primus models. The more compact Primus-PR model is ideal for use in small and medium-sized agricultural operations.
- Quick-change plug-in system D12
- Kränzle in-line pump
- Total stop system with delayed motor shutdown
- Safety shutdown
- Infinitely variable pressure regulation
- Twist-stop anti-twist protection
- Roll-on and roll-off aid
- Ordering system
- Roto-mold chassis
- Large stainless steel pressure gauge
- Operating pressure
- 30-170 bar
- Water output
- 15 l/min
- Motor speed
- 1400 U/min
- Connection Voltage
- 400 V
- Connection Phase
- 3 ~
- Connection Frequency
- 50 Hz
Technical details
Primus-RP 900 TST
Ord. no. 614140
| ||
|---|---|---|
| Ord. no. | 614140 | |
| Operating pressure | bar | Primus-RP 900 TST 30-170 bar |
| Operating pressure | MPa | Primus-RP 900 TST 3-17 MPa |
| Water output | l/h | Primus-RP 900 TST 900 l/h |
| Admissible overpressure | bar | Primus-RP 900 TST 190 bar |
| Admissible overpressure | MPa | Primus-RP 900 TST 19 MPa |
| Motor speed | U/min | Primus-RP 900 TST 1400 U/min |
| Connection Voltage | V | Primus-RP 900 TST 400 V |
| Connection Phase | ~ | Primus-RP 900 TST 3 ~ |
| Connection Frequency | Hz | Primus-RP 900 TST 50 Hz |
| Connection Amperage | A | Primus-RP 900 TST 9,4 A |
| Power intake | kW | Primus-RP 900 TST 5,5 kW |
| Power output | kW | Primus-RP 900 TST 4,0 kW |
| Power supply cable Length | m | Primus-RP 900 TST 7.5 m |
| Length | mm | Primus-RP 900 TST 600 mm |
| Width | mm | Primus-RP 900 TST 465 mm |
| Height | mm | Primus-RP 900 TST 995 mm |
| Weight | kg | Primus-RP 900 TST 59 kg |
