KRÄNZLE WS-RP-Serie | Hochdruckreiniger Kaltwasser

WSC-RP 1400 TS

Ord. no. 622150

The stationary cold water high-pressure cleaners of the WS(C)-RP series can be mounted either on the floor or on the wall. The Kränzle in-line pump allows high water volumes at the highest working pressure to remove even the most stubborn dirt. The optional stainless steel cover protects the high-pressure pump from dirt (WSC-RP).

Quick-change plug-in system D12
Kränzle in-line pump
Stand and wall-mounted unit
Total stop system with delayed motor shutdown
Safety shutdown
Pressure regulation
Twist-stop anti-twist protection
Wall bracket
Ordering system
Large stainless steel pressure gauge
Stainless steel cover

Operating pressure: 30-170 bar

Water output: 23.3 l/min

Motor speed: 1400 U/min

Connection Voltage: 400 V

Connection Phase: 3 ~

Connection Frequency: 50 Hz

Technical details

		WSC-RP 1000 TS Ord. no. 622112	WSC-RP 1200 TS Ord. no. 622132	WSC-RP 1400 TS Ord. no. 622150	WSC-RP 1600 TS Ord. no. 622170
Ord. no.		622112	622132	622150	622170
Operating pressure	bar	WSC-RP 1000 TS 30-200 bar	WSC-RP 1200 TS 30-190 bar	WSC-RP 1400 TS 30-170 bar	WSC-RP 1600 TS 30-150 bar
Operating pressure	MPa	WSC-RP 1000 TS 3-20 MPa	WSC-RP 1200 TS 3-19 MPa	WSC-RP 1400 TS 3-17 MPa	WSC-RP 1600 TS 3-15 MPa
Water output	l/h	WSC-RP 1000 TS 1000 l/h	WSC-RP 1200 TS 1200 l/h	WSC-RP 1400 TS 1400 l/h	WSC-RP 1600 TS 1600 l/h
Admissible overpressure	bar	WSC-RP 1000 TS 220 bar	WSC-RP 1200 TS 210 bar	WSC-RP 1400 TS 200 bar	WSC-RP 1600 TS 170 bar
Admissible overpressure	MPa	WSC-RP 1000 TS 22 MPa	WSC-RP 1200 TS 21 MPa	WSC-RP 1400 TS 20 MPa	WSC-RP 1600 TS 17 MPa
Motor speed	U/min	WSC-RP 1000 TS 1400 U/min	WSC-RP 1200 TS 1400 U/min	WSC-RP 1400 TS 1400 U/min	WSC-RP 1600 TS 1400 U/min
Connection Voltage	V	WSC-RP 1000 TS 400 V	WSC-RP 1200 TS 400 V	WSC-RP 1400 TS 400 V	WSC-RP 1600 TS 400 V
Connection Phase	~	WSC-RP 1000 TS 3 ~	WSC-RP 1200 TS 3 ~	WSC-RP 1400 TS 3 ~	WSC-RP 1600 TS 3 ~
Connection Frequency	Hz	WSC-RP 1000 TS 50 Hz	WSC-RP 1200 TS 50 Hz	WSC-RP 1400 TS 50 Hz	WSC-RP 1600 TS 50 Hz
Connection Amperage	A	WSC-RP 1000 TS 13,5 A	WSC-RP 1200 TS 14,3 A	WSC-RP 1400 TS 14,3 A	WSC-RP 1600 TS 14,3 A
Power intake	kW	WSC-RP 1000 TS 7,5 kW	WSC-RP 1200 TS 7,5 kW	WSC-RP 1400 TS 8 kW	WSC-RP 1600 TS 8 kW
Power output	kW	WSC-RP 1000 TS 5,5 kW	WSC-RP 1200 TS 5,5 kW	WSC-RP 1400 TS 6,3 kW	WSC-RP 1600 TS 6,3 kW
Power supply cable Length	m	WSC-RP 1000 TS 7.5 m	WSC-RP 1200 TS 7.5 m	WSC-RP 1400 TS 7.5 m	WSC-RP 1600 TS 7.5 m
Length	mm	WSC-RP 1000 TS 670 mm	WSC-RP 1200 TS 670 mm	WSC-RP 1400 TS 670 mm	WSC-RP 1600 TS 670 mm
Width	mm	WSC-RP 1000 TS 430 mm	WSC-RP 1200 TS 430 mm	WSC-RP 1400 TS 430 mm	WSC-RP 1600 TS 430 mm
Height	mm	WSC-RP 1000 TS 510 mm	WSC-RP 1200 TS 510 mm	WSC-RP 1400 TS 510 mm	WSC-RP 1600 TS 510 mm
Weight	kg	WSC-RP 1000 TS 65 kg	WSC-RP 1200 TS 65 kg	WSC-RP 1400 TS 65 kg	WSC-RP 1600 TS 65 kg

Downloads

Operating instruction
